stainles steel 304 for all "L" bracket and U bolt mounting screw kit omni 4G 8dbi dual polarization M2M&IoT antenna

IP66 waterproof 4G antenna

This high gain multiband 4G omni antenna WH-4G-MM8x2 is designed for dual polarizontal 700MHz (2G / 4G), 900Mhz (4G), 1800MHz (3G / 4G), 2100MHz (4G) and 2700MHz (4G) frequency band and supports all established standards like GSM, 2G, 3G and 4G (800 / 900 / 1800 / 2100 / 2700).The antenna WH-4G-MM8x2 has a gain of up to 8dBiX2 and helps you to improve your 2G, 3G or 4G connection even on long distances.

individual box package

Cable

Optionally we offer a pair of antenna cables of type RG58U with a length of 2.5m, 5m, 10m and 15m with N male to SMA male (fits to the most common LTE routers ) connectors.

individual box package

stainles steel 304 for all "L" bracket and U bolt mounting screw kit ;allow working for marine

brand:
whwireless
item no.:
WH-4G-MM8x2
payment:
T/T,Alipay,WeChat Pay,Paypal
product origin:
china
color:
white
lead time：
7working day

Inquiry now WhatsApp

Frequency Range :700-960/1710-2170/2300-2400/2500-2700MHz
Band width :260/460/100/200MHz
Gain :6/8dBi
V.S.W.R :≤2:1
Radiation :Omni-Direction
Horizontal Beam width:360°
Vertical Beam width :18°
Polarization :Vertical&Horizontal
Lightning Protection:DC-Grounded
Maximum Input Power :100W
Impedance:50Ώ
Connector :N Female or customized
Antenna Radome Material:PVC
Mount way :Pole
Diameter of Installation Pole:Ø30~Ø50mm

Dimensions:Φ75x640mm

Material of bracket:stainles steel 304 for all "L" bracket and U bolt kits

Weight:1KG
Operating Temperature:-40℃ to+70℃
Rated wind velocity(m/s):60m/s
RoHS Compliant:YES
