5G NR panel mimo antenna

5G NR mimo panel antenna

5G NR antenna

  • brand:

    whwireless
  • item no.:

    WH-5G-D15X2
  • payment:

    T/T
  • product origin:

    china
  • color:

    white
  • lead time:

    8working day
Inquiry now

Frequency range-MHz:3400-3800

Bandwidth -MHz:400

Gain-dBi:15

Horizontal Beam width-°:35

Vertical Beam width-°:30

F/B-dB:17

VSWR:≤1.5

Input Impedance -Ω:50

Polarization:Horizontal and Vertical

Maximum input power -W:20

Connector:2xSMA


Dimensions -mm:200X200X40

Pole-mm:Φ25-52

Weight-kg:0.5


Waterproof IP65

MOQ:5PCS

SPQ:20PCS/box

Ddelivery time:8working day

Payment term:T/T

Package:plastic bag and box

Paymeter method:Paypal;Wire Transfer

Customized according client require detail

Shiping way:DHL Fedex UPS OR Air FBA

Send a Message

If you have questions or suggestions,please leave us a message,we will reply you as soon as we can!
