Modular 2.4GHz wifi wireless comms wlan terminal router antenna

2.4GHz patch antenna

wlan patch antenna;indoor or outdoor  antenna

short fiberglass antenna

WHWIRELESS Enclosures and antennas play crucial roles in wireless communication systems, especially in industrial settings like the depicted water - treatment or industrial plant. The WH-R-235 enclosure, come with dimensions 268×268×65mm (outer) and 233×233×55mm (inner), has an IP66 waterproof rating. This makes it suitable for harsh outdoor environments, protecting internal components from dust and water ingress. The WH-2.4G-NL4 antenna operates in the 2400-2483MHz frequency range with a 4dBi gain. Its size of φ20×300mm and N male connector enable efficient signal transmission and reception, facilitating seamless communication within the facility. Together, they ensure reliable connectivity and system performance.

whwireless antenna model WH-2400-03 apply to the outdoor gateway mounting on control cabinet; come with N male;3dBi 2400MHz small dimension φ19X60mm

WH-5G-010X2 is a wideband 5G 4G LTE mimo antenna that covers cellular frequencies in the range from 700 to 2700/3300/3500/3800MHz. In additional to 3G and 4G wireless applications, the antenna covers IoT technologies such as LoRa, Sigfox, and others using unlicensed bands such as 868 and 915 MHz. ISM 2.4GHz WiFi and Bluetooth 3.0 are also fully supported. The model has a 8dBix2 gain on the lower 698 to 960 MHz range and 10dBiX2 gain on the upper 1710 to 2700 MHz and 5G 3300/3500/3800MHz range. These peak gain figures are ideal for maintaining a near-spherical radiation pattern, very important for use in IoT, machine telemetry, and metering applications.

This FPC 5G 4G mimo antenna WH-5G-FPC6x2 is designed for terminal FPC antenna covering 618/700-960/1710/1800/2700/4800/6000MHz ( 5G 4G 3G), Designed for terminals and routers, the antenna offers SMA or U.FL connector for flexible positioning and stick on metal or window smooth surface. Easy install 3M adhesive mounting.

11dbi yagi antenna RP-TNC male 7element LPWAN, LoRA, IoT, M2M applications The whwireless WH-900MHz-YD11 High-Performance Yagi Antenna come with high gain with a wide 50° beam-width. It is ideally suited for directional applications in the 900GHz ISM and LPWAN bands as well as IoT and Point to Multi-Point communication. Typical applications include 900 MHz Wireless LAN, SCADA, LPWAN, LoRA, IoT, M2M, and 900 MHz Cellular.
