5G iot magnet Antennas

Compatible with LTE, GSM, CDMA, PCS,2G 3G;4G 5G NR network wireless devices

whwireless antenna model WH-5G-Z06 Boost your outdoor cellular network by 6dBi 4G 5G Omni-Directional MIMO Antenna WH-5G-Z06. Our high-performance antenna operates within the 600-6000MHz frequency range, providing excellent signal coverage and transmission for both 4G and 5G networks. This antenna is designed to support multiple band wireless communications, ensuring compatibility with a wide range of cellular networks. With its omni-directional design, this antenna provides 360-degree coverage and is perfect for use as a wireless gateway antenna. Its vertical polarization ensures optimal signal strength, while its rugged construction makes it suitable for use in harsh outdoor environments. Whether you need to enhance your home or business network, the WH-5G-Z06 MIMO antenna is an ideal choice for reliable and high-speed connectivity.

The WH-4G-D3X3 wireless signal cover antenna offers advanced connectivity and positioning performance, drawing on the expertise found in WH Wireless’s 3-in-1 GNSS/5G antenna solutions. (See WH’s product page for reference.) The antenna operates across broad 5G bands (698-960 / 1710 / 2700 / 3500 / 3800 MHz) and GNSS frequencies (1559-1608 MHz), delivering both high-speed data and precise satellite positioning. Its gain of 3 dBi / 28 dBi ensures robust signal coverage and improved link margins in challenging RF environments. Designed for durability, it features a compact, weather-resistant enclosure (Φ143 × 32 mm) and comes with three SMA male connectors to accommodate multi-band radio systems. The WH-4G-D3X3 is ideal for use on rooftops, control towers, terminals, and large-scale installations where strong 5G coverage and GNSS accuracy are critical. { "@context": "https://schema.org", "@type": "FAQPage", "mainEntity": [ { "@type": "Question", "name": "What does '3-in-1' mean in this GLONASS 5G combination antenna?", "acceptedAnswer": { "@type": "Answer", "text": "This 3-in-1 combination antenna integrates three separate antenna elements into a single, compact housing. It typically features one GLONASS/GPS element for precise global positioning, and two 5G/LTE elements (MIMO) for high-speed, stable cellular data connectivity." } }, { "@type": "Question", "name": "What frequency ranges does this 5G GLONASS antenna cover?", "acceptedAnswer": { "@type": "Answer", "text": "The 5G elements cover global Sub-6GHz frequencies (typically 600-6000 MHz), ensuring full compatibility with 5G NR, 4G LTE, and 3G networks. The GLONASS element operates on standard satellite navigation frequencies (1575.42 MHz & 1598-1606 MHz) to provide accurate location tracking." } }, { "@type": "Question", "name": "What are the primary applications for this multi-band antenna?", "acceptedAnswer": { "@type": "Answer", "text": "It is widely used for vehicle telematics, fleet management systems, public transportation, police and emergency vehicles, industrial 5G routers, and IoT gateways where both real-time location tracking and high-bandwidth data transmission are required." } }, { "@type": "Question", "name": "Is this 3-in-1 antenna waterproof and suitable for vehicle mounting?", "acceptedAnswer": { "@type": "Answer", "text": "Yes, the antenna features a rugged, low-profile radome with an IP67 waterproof and UV-resistant rating. It is designed for harsh outdoor environments and is usually installed via a secure, heavy-duty screw mount (through-hole) on vehicle roofs or industrial cabinets." } }, { "@type": "Question", "name": "Can WHWireless customize the cable length and connectors for my 5G router?", "acceptedAnswer": { "@type": "Answer", "text": "Absolutely. WHWireless offers flexible OEM/ODM customization. You can specify the exact cable length and choose your required connectors (such as SMA Male for 5G, SMA for GLONASS, or FAKRA connectors) to ensure seamless integration ...

Iot 5G/4G/LTE terminal antennas WH-5G-08 complement Mobile LTE broad line of antenna products for Cellular applications. Antenna with performance of 7-8dBi max(frequency dependent).

5G NR M2M antenna; small dimension,high performance 4G M2M antenna; pole copper material;high performance； Easy install Mounting magnet bast One time die casting IP67 waterproof antenna base;pole copper material;high performance is a compact, high performance, magnetic mount antenna suitable for use with any 5G 4G LTE compatible modem or gateway. comes with a magnetic base for temporary mounting situations and performs across six major cellular, GSM, and LTE bands supporting 2G, 3G and 4G cellular technologies.

Cabinet antennas WH-5G-0Y4.5  provide an ideal solution for modem devices whether for domestic or business wireless data or for machine to machine applications and connected devices. This 5G/4G antenna works perfectly with LTE /5G 4G devices which have external antenna port. Comes complete with RG58 cable terminated with an SMA male connector(customized) and mounting L shape bracket.waterproof level IP65;screw part (M14 normal;M16 customized) can be wall mount or magnet

WHWIRELESS WH-5G-FPC10 The FPC antenna, optimized for 5G frequencies spanning 700, 960, 1710, 1800, 2700, 3600, and 4800MHz, boasts exceptional versatility and performance. With a high gain of 10dBi, it ensures robust signal reception across diverse frequency bands, enabling seamless connectivity in various environments. The antenna's flexible printed circuit (FPC) design enhances durability and allows for easy integration into compact devices or complex installations. Equipped with a U.FL cable, it facilitates straightforward connection to compatible devices, ensuring hassle-free setup. Whether deployed in urban centers, rural areas, or industrial settings, this antenna delivers reliable 5G connectivity, empowering users with high-speed data transfer, low latency, and enhanced network performance. Its wide frequency coverage and impressive gain make it an ideal choice for applications demanding superior wireless communication capabilities

WHWIRELESS 5G CBRS MIMO 2x2 antenna WH-5G-06X2 is a high-performance antenna system designed to deliver fast and reliable data connectivity in 5G cellular networks operating in the CBRS frequency band. This antenna utilizes MIMO technology, featuring two independent antenna elements capable of transmitting and receiving signals simultaneously, which increases data throughput and improves signal quality. Designed for outdoor use, this antenna has a compact size and comes equipped with advanced beamforming technology, allowing for more precise targeting of signals and enhanced overall performance. It has a gain ranging from 4 to 6 dBi, up to four ports, and Type N connectors. The antenna also features UV-protected radomes, ensuring long operating life even in harsh weather conditions. This 2x2 antenna is suitable for SISO and MIMO networks and is part of a portfolio of outdoor antennas that cover most extended CBRS and 5G/4G/3G/2G applications in licensed and unlicensed frequencies. It is an ideal solution for a wide range of applications, including commercial and industrial settings, where high-speed data connectivity and reliable signal quality are critical.
