5.8GHz GSM GPS WLAN antenna combine antenna

2dBi SMA GPS GSM combine antenna,terminal ntenna

GPS GSM combine antenna GPS GSM combine screw mounting antenna GPS GSM combine antenna


  • brand:

    whwireless
  • item no.:

    WH-GPS-GSM-5.8GHz
  • payment:

    T/T
  • product origin:

    china
  • color:

    black
  • lead time:

    5working day

GPS

Frequency:1575.42 MHz

Bandwidth:±5 MHz

Gain:28dbix2

Noise Figure:1.5dB

DC Voltage:2.2-5V

DC Current:5-15mA

Impedance:50 Ω

VSWR:≤1.5

Polarization:RHCP

Nominal Impedance:50 -Ω

GSM&5.8GHz

Frequencey:824~960MHz/1710~1990MHz/5725-5850mhz

VSWR:≤2.0︰1

Gain:2 dBi

Impedance:50 Ω
cable:RG174 3m/ or others

Connector:SMA/SMB/MCX or others

Plastic Housing:Black

Mounting:Screw

Waterproof IP66

MOQ:2PCS

SPQ:100PCS/box

Ddelivery time:5working day

Payment term:T/T

Package:plastic bag and box

Paymeter method:Paypal;Wire Transfer

Customized according client require detail

Shiping way:DHL Fedex UPS OR Air FBA
