Point to multi-point systems Wireless Bridge antenna

Φ94.5×73.5mm
N male
IP67 N male directly
2.4G Wifi Antenna;apply to outdoor router
  • brand:

    whwireless
  • item no.:

    WH-2.4GHz-0D3
Inquiry now
Frequency(MHz) :2400-2483MHz
Band Width(MHz) :83 MHz
V.S.W.R(in BW) :1.5︰1
Gain(Zenith) :3 dB ±0.5 dB
Polarization :vertical
Impedance :50 Ω

Connector :N male or customized
Plastic Housing :White
Mounting :Screw
Breath holes diameter :2mm X2
Connector :N male
dimension:Φ94.5×73.5mm
Water proof:IP67 with O ring
Weight:165.5g

Mesh networking applications
• 2.4 GHz wireless applications
• Point to multi-point systems
Base station antennas
WiFi access points
• WiMax base stations
• IEEE 802.11b/g WLAN Systems
2.4/5GHz WLAN,WiFi system
• Video surveillance camera solutions
• Wireless Bridge
